GZT Vibrating Feeder

GZT Vibrating Feeder

Model: GZT0724 -- GZT1560



Max Feed Size: 450 - 1000 (mm)



Capacity: 30 - 600 (t/h)



Application: Mine, cement, lime, quarry crushing and screening plant.

Whatsapp: +86 18037866379
Send e-mail: mic@zkcorp.com
Leave a Message
Chat Online

Introduction

GZT Vibrating Feeder is designed by our company absorbing advanced technology home and abroad, and adopts vibrating motor to produce vibration force. It can send large material into the crushers evenly. At the same time, by using the bar screen deck, materials such as soil which can be crushed easily will be removed and the carase crushing capacity is improved.

GZT Vibrating Feeder use a pair of motor with complete same parameter as vibrating source. It can continuously and uniformly feed lump, granulate material to receiving equipment. and screen material during feeding process. It has feature such as big vibrating force, high strength, impact resistance, long service.

Application of Vibrating Feeder :
It is widely used for feeding big size material for crushing in mine, cement, lime, ore dressing industries, etc.

Features

1. Vibrating source is motor, small noise, strong vibrating force. Low energy consumption.

2. Stable vibrating force and easy adjustment, can change and control material feeding any time.

3. Gap between stick on outlet are adjustable. It can separate soil and sand during feeding process, the pre-screen capability can improve the coarse crushing capacity.

4. Material trough use frame type connect with rivet, and side plate is bend by a entire steel plate, compact structure, good rigidity, fatigue resistance.

5. Both backplate and stick are made by ware-resistant material, strong structure, high strength, impact resistance.

6. Big processing capacity, reliable running, easy maintenance.

Parameter

Model

Max Feeding Size
(mm)

Capacity
(t/h)

Motor Power
(kW)

Angle
(°)

Weight
(kg)

GZT-0724

450

30~80

2×1.5

10

2936

GZT-0932

560

80~150

2×2.4

10

3359

GZT-0940

560

80~180

2×3.2

10

3608

GZT-1148

600

150~300

2×5.5

10

4808

GZT-1256

800

180~400

2×7.5

10

5994

GZT-1560

1000

400~600

2×13

10

9896
