ZK series linear vibrating screen is based on the needs of China's production in the digestion and absorption shaker from abroad on the basis of summing up of our years of research experience in the design and use, combined with the national conditions , China developed this new series of vibrating screen.

Through years of practice, that the series of machine has to deal with a large amount of technical parameters of a reasonable structural strength, high stiffness, serialization, generic, and a high degree of standardization, smooth and reliable operation, low noise, maintenance overhaul to facilitate a series of advantages

Linear vibrating screen can screen and classify powder and granular material. It is applied widely in plastics, abrasives, chemicals, pharmaceuticals, building materials, food, carbon, fertilizer and other industries.

Features

1. It has unique design for the screen, and is easy and fast to change screen(only need 3-5minutes), plus, this design allows to use every kind of screen(nylon, special type nylon and PP net).

2. It is ingenious and easy for assembling, one person can operate the vibrating screen.

3. Compared with other brands, it has larger sieving area and high processing capacity with high efficiency.

4. High degree of standardization, smooth and reliable operation; Large capacity, high strength, stable and reliable performance; Reasonable structural strength, high stiffness, serialization, generic;

Parameter

Model	Sieve      Specifi-      cations	Sieve  layer	Mesh      size	Feeding  size	Cap-acity	Motor Power	Total      Weight	Vibr-ating frequ-ency	Double ampl-      itude	Sieve      obliq-uity	Dimensions
	(L*W)(mm)	Layer	mm	mm	(t/h)	kw	kg	(Hz)	(mm)	o	L*W*H(mm)
ZSG1237	3700*1200	1	4-50	<=200	10-100	5.5*2	2250	16	6-8	15	3800*2050*1920
2ZSG1237	3700*1200	2	4-50	<=200	10-100	5.5*2	3345	16	6-8	15	3800*2050*2200
ZSG1443	4300*1400	1	4-50	<=200	10-150	5.5*2	4100	16	6-8	15	4500*3040*2500
2ZSG1443	4300*1400	2	4-50	<=200	10-150	5.5*2	4900	16	6-8	15	4500*3040*2700
3ZSG1443	4300*1400	3	4-50	<=200	10-150	5.5*2	5870	16	6-8	15	4500*3040*2820
2ZSG1548	4800*1500	2	5-50	<=200	15-200	7.5*2	5836	16	8-10	15	4800*3140*2814
3ZSG1548	4800*1500	3	5-50	<=200	15-200	7.5*2	6900	16	8-10	15	4799*3140*3014
2ZSG1848	4800*1800	2	5-50	<=300	50-500	7.5*2	6489	16	8-10	15	4799*3440*2814
3ZSG1848	4800*1800	3	5-50	<=300	50-500	7.5*2	7750	16	8-10	15	4799*3440*3014
4ZSG1848	4800*1800	4	5-50	<=200	50-500	11*2	8300	16	8-10	15	4799*3440*3503
2ZSG1860	6000*1800	2	5-150	<=300	80-600	11*2	9950	16	8-10	15	6000*3440*3326
